Hypertherm Plasma Power Supply HPR260XD
The Hypertherm HPR260XD Plasma Power Supply is designed for use with high-end CNC plasma cutting machines. It provides powerful cutting capabilities and high precision, optimizing metal cutting processes across various industrial applications.
Hypertherm HPR260XD Plasma Power Supply
The Hypertherm HPR260XD is a high-performance plasma cutting system, engineered to deliver precise and efficient cutting for a wide range of metal materials, including carbon steel, stainless steel, and aluminum. Equipped with HyPerformance Plasma technology, this system ensures high accuracy, clean cuts, and minimal slag.
Specifications:
- Product Name: Hypertherm HPR260XD Plasma Power Supply
- Model: HPR260XD
- Brand: Hypertherm
- Authorized Distributor in Vietnam: LECI
- Power Supply: 3-phase, 220/380/400V, 50/60Hz
- Cutting Voltage: 175 VDC
- Open Circuit Voltage: 311 VDC
- Duty Cycle: 100% at 260A
- Max Cutting Current: 260A
- Dimensions (LxWxH): 1190mm x 820mm x 1150mm
- Weight: 567 kg
- Cutting Capacity: Can cut up to 64mm
- Applications: HPR260XD is used to cut carbon steel, stainless steel, copper, aluminum, etc.
Cutting Gases:
- Plasma Gas: O2, N2, F5, H35, Air
- Shield Gas: N2, O2, Air
- Gas Pressure: 8.3 bar
Learn more: LECI - Hypertherm Authorized Distributor in Vietnam
True Hole Technology in Hypertherm HPR260XD
Hypertherm True Hole Technology enables the HPR260XD power supply to deliver superior cutting precision and quality. True Hole improves roundness and sharpness of holes, reducing distortion and slag commonly found in traditional plasma cutting. This eliminates the need for manual post-processing, saving both time and costs.
Clean, Precise Cuts:
- Carbon Steel: Up to 32 mm
- Stainless Steel: Up to 32 mm
- Versatile Applications:
- Carbon Steel: Up to 38 mm
- Stainless Steel: Up to 50 mm
- Maximum Cutting Capacity (edge starts):
- Carbon Steel: Up to 64 mm
- Stainless Steel: Up to 50 mm
Learn more: Hypertherm MaxPro200 Plasma Power Supply
Key Features of Hypertherm HPR260XD
- Powerful Cutting: Delivers up to 260A, allowing for easy cutting of thick metal plates.
- Fast and Efficient: High cutting speed optimizes productivity and reduces machining time.
- High-Quality Cuts: Sharp, smooth cuts minimize the need for post-processing.
- Cost-Effective: Reduced consumables and energy usage, along with the long lifespan of torches and electrodes, lower operational costs.
- Precision: Achieves perfect round holes, even on thick materials.
- Minimal Slag: Clean cuts with fewer burrs, enhancing overall product quality.
- No Adjustments Required: Delivers optimal hole quality without special settings or manual intervention.
LECI specializes in supplying Hypertherm plasma power supplies, nozzle, and other components. We offer expert consultation and CNC machine repair services.
