Compact, air cooled UV table top unit with curing combination UV LED and UV tube. The UV light emitting diodes (LED) and the experienced UV tube can be used for the curing of special UV inks, UV varnishes and UV adhesives for a broad range of small format. Ideal for tests, R & D or occasional small production runs of small size flat material and moulded parts.
| UV LED wave length | 395 nm (other wave lengths on request) |
| UV LED power | 16 W/cm², infinitely variable (other powers on request) |
| UV LED curing width | 16 cm |
| UV tube | 20 cm, Hg (ozone free tube and special spectra on request) |
| Max. curing width UV tube | 20 cm |
| UV power | max. 120 W/cm, variable power adjustment from 30-100% |
| Conveyor belt speed | 3-20 m/min. (other speeds on request), variable |
| Conveyor belt | Teflon coated, endless, glass fibre conveyor belt, black, antistatic |
| Conveyor belt width | 25 cm |
| Pass through width | approx. 30 cm |
| Tunnel height | adjustable in steps up to approx. 50 mm |
| Features | LED: High stabilized, infinitely variable LED UV power.
Low heat load on the material.
Inclusive belt suction. |
| Colour | RAL 5002, blue and RAL 7035, grey |
| Manual instruction | German or English |
| Note | Installation of waste air required (UV tube creates ozone).
Power supply and electrical fusing are up to the customer.
When increased tunnel height is used, ensure that max. light emission limit is not
exceeded! |
