Incure Ultra-Illumina 3511B is a premium-grade, black UV-curable conformal coating formulated specifically for printed circuit board assembly (PCBA). This low-viscosity, fast-curing resin delivers a resilient, glossy, and opaque protective layer that safeguards electronics from moisture, dust, and harsh environmental conditions.
Features
- Superior Environmental Protection: The black, opaque finish forms a tough and glossy moisture barrier, ideal for both indoor and outdoor electronics exposed to humidity and contaminants.
- Dual-Cure Capability: While the coating rapidly cures under UV light, shaded areas beneath components are fully cured via a secondary heat-curing process.
- Eco-Friendly Composition: 100% solids, solvent-free formulation with no volatile organic compounds (VOCs), supporting sustainable manufacturing practices.
- Outstanding Mechanical Performance: Delivers tensile strength of up to 5,700 psi, Shore hardness of D75–D85, and excellent resistance to thermal stress.
- International Compliance: Certified to UL 746C, 94V-0 flame rating, RoHS, and Halogen-Free (HF) standards.
Specifications
| Property | Value |
| Chemical Type | Urethane Acrylate, 100% solids, solvent-free |
| Color | Opaque Black |
| Viscosity | 160 cP (measured at 25°C) |
| Shore Hardness | D75 – D85 (ASTM D2240) |
| Tensile Strength | 4,400 – 5,700 psi |
| Elongation at Break | 15% (ASTM D638) |
| Water Absorption (24 hrs) | 0.50% (ASTM D2566) |
| Linear Shrinkage/Expansion | < 0.20% (ASTM 570) |
| Thermal Range | -55°C to +155°C |
| Thermal Resistance | Excellent; no brittleness after heat aging |
| Secondary Heat Cure | 125°C for 30 min or 95°C for 120 min |
| Shelf Life | Minimum 1 year (when stored properly) |
Applications
- Protective coating for PCBA in industrial and consumer electronics
- Optical or RF devices where light shielding is critical
- Electronics exposed to harsh operating conditions including temperature cycling and humidity
- Ideal for manufacturers requiring fast UV curing with high throughput and reliability
Advantages Over Traditional Coatings
- Instant UV cure without long drying times required by epoxy systems
- Reduced labor and increased production efficiency
- Minimal shrinkage, no surface cracking or deformation
- Optional inspection under UV fluorescence (if required)
