LECI supplies a wide range of Laser lenses from Raytools, WSX, Precitec, and Bochu, including models such as BT210, BT210S, BT240S, BM109, BT110, BT112S, BM111, BM114, BM115, KC13, KC15, NC30, NC60, LightCutter, HPSSL, and ProCutter. Simply send us a picture of the product, and we will advise on the appropriate specifications and lens types.

Laser Lenses - Focusing Lenses - Collimating Lenses

Laser Fiber Lenses are used in fiber laser systems and play a critical role in determining laser beam quality and machining efficiency.

Raytools Laser Lenses

The Raytools laser lenses include BT210, BT210S, BT240S, BM109, BT110, BT112S, BM111, BM114, and BM115, corresponding to various Raytools cutting heads.

Raytools Focusing Lenses

Key models of Raytools focusing lenses include: D28 F125/150, D30 DF125/150/155/200, D30 F150/200, D37 F150/200, D38.1 F200, D37 F150/200 for machines with power capacities of 4000W, 1500W, 3300W, 6000W, and 8000W.

Raytools Collimating Lenses

For Raytools collimating lenses, commonly available models include: D28 F75/100, D30 F100, D28 F100, D30 F100, and D37 F100. These lenses are essential for ensuring the parallelism of the laser beam before it is focused, contributing to precise cutting and engraving performance.

WSX Laser Lenses

Corresponding to each cutting head, WSX laser lenses include both focusing and collimating lenses such as: KC13, KC15, NC30, and NC60. These lenses help optimize the cutting process, ensuring precision and high performance during operation.

WSX Laser Focusing Lenses

Focusing lenses for WSX cutting heads consist of common models like D30 F125/150/190 and D37 F150/190, which are designed to enhance cutting accuracy and efficiency.

WSX Laser Collimating Lenses

Each WSX cutting head is compatible with specific laser collimating lenses. Common models include the D30 F75/100 and D37 F100 collimating lenses, which are essential for maintaining beam parallelism, ensuring optimal performance and precision during laser cutting operations.

Precitec Laser Lenses

Precitec laser cutting heads are compatible with various types of lenses, including the LightCutter, HPSSL, and ProCutter series.

Precitec Laser Focusing Lenses

Common focusing lenses for Precitec lasers include D30 F125/150 and D37 F125/150, which are designed to enhance cutting precision and efficiency across different materials.

Precitec Laser Diverging Lenses

Precitec laser lenses include diverging lenses such as D30 F100 and D37 F100, suitable for high-power machines with capacities of 4000W, 6000W, 8000W, 12KW, and 15KW. These lenses ensure optimal beam control and enhance cutting performance at higher power levels.

Fiber Laser Lenses

The fiber laser lens system plays a crucial role in ensuring the performance and precision of fiber laser machines. These lenses serve various functions, such as focusing the laser beam, protecting the lenses, and optimizing the machining process, delivering high-quality results in a wide range of industrial applications.

The fiber laser lens system includes:

• Focusing Lens: Concentrates the laser beam into a small point, increasing energy density for precise cutting and engraving on materials like metal, plastic, and wood.
• Collimating Lens: Diverges or expands the laser beam, keeping it stable over long distances to maintain high performance.
• Protection Lens: Shields the main lenses from dust and debris, extending the lifespan of the lenses and reducing maintenance costs.

What is a Fiber Laser Focusing Lens?

A focusing lens is used to concentrate the laser beam into a small point, increasing energy density to enable high-precision cutting, engraving, or machining. It is positioned near the end of the optical system, just before the laser beam hits the material surface.

What is a Fiber Laser Collimating Lens?

A collimating lens diverges or spreads the laser beam, keeping it parallel and preventing early focus, ensuring the beam quality is maintained over long distances. It is typically placed at the beginning of the optical system or after the laser source, before the beam passes through the focusing lens.

Why Choose LECI for Laser Lenses?

• In-stock Availability: LECI always has inventory on hand, ensuring same-day delivery.
• Wide Product Range: We provide a full range of laser lenses and related components.
• 24/7 Consultation: Just send us a photo of the product, and we will advise on the specifications and the appropriate lens for your needs.
