The F400 UV flood lamp is a compact, portable UV curing solution ideal for batch production, lab use, or mobile UV bonding applications. It delivers effective exposure across a 5” x 5” curing area, and is powered by a state-of-the-art arc lamp system, with optional UVA or UVC wavelengths.
The detachable lamp head functions independently for handheld operation, while the bottom section acts as a carrying case for accessories, including cables, lamp rest, and UV glasses.
Features
- Integrated lamp + accessories box
- Lightweight and portable (6 lbs)
- UVA (365nm) or UVC (254nm) wavelength options
- Air-cooled for extended lamp life
- Ideal for field use, laboratory, or on-demand curing
- Ready to use – no complicated setup required
Specifications
| Parameter | Value |
| Lamp Type | ARC Flood (Metal Halide arc) |
| Peak Intensity | UVA: 415–310 mW/cm²
UVC: 390–300 mW/cm² |
| Wavelength Options | 254 nm / 365 nm |
| Working Distance | 1” – 3” |
| Curing Area | 5” x 5” (127 x 127 mm) |
| Lamp Life | >1000 hrs |
| Cooling | Forced Air with Louvers |
| Adjustable Heights | 1.75" / 3.5" / 5.25" / 7.0" / 9.0" |
| Dimensions (Light Source) | 8” x 5” x 6” |
| Power Supply Dimensions | Integrated inside 12” x 12” x 12” enclosure |
| Power Input | 100–240V AC, 50/60Hz Auto-Ranging |
| Weight | 6 lbs (~2.7 kg) |
| Order Numbers | F400-1A (UVA bulb), F400-1C (UVC bulb) |
