The INCURE F100/200 is a compact UV flood curing lamp. F100/F200 integrates all system components into a small lamp head which can be easily mounted anywhere on a factory floor, with virtually no cabling or remote control boxes required. Just mount the head, connect the AC line cord, and start curing! The long life 400/600-Watt metal halide type lamp and parabolic reflector illuminate an 8 x 6 inch curing area with evenly distributed 100mW/cm2 UVA light (320–390nm). The arc lamp is powered by the state of the art UV Power-Plus Lamp Driver. The head features a convenient carrying handle and sliding height adjustment bracket.
| Product | Product Highlights | Lamp Type | Weight (lbs.) |
| UV Flood Curing Lamp F100 | F100 integrates all system components into a small lamp head which can be easily mounted anywhere on a factory floor, with virtually no cabling or remote control boxes required | 400 Watt Metal Halide | 13 Pounds |
| UV Flood Curing Lamp F200 | F200 integrates all system components into a small lamp head which can be easily mounted anywhere on a factory floor, with virtually no cabling or remote control boxes required | 600 Watt Metal Halide | 13 Pounds |
| Configuration | F100 | F200 |
| Order Number | 290005 | 290033 |
| Input Voltage | 90-132/180-265VAC | 90-132/180-265VAC |
| Input Current, 120/240V | 7A/3.5A maximum | 10A/5.0A maximum |
| Source Input Frequency | 47 Hz to 63 Hz | 47 Hz to 63 Hz |
| Lamp Power Regulation | ± 1% | ± 1% |
| Fan / Auxiliary Voltage | 24V | 24V |
| Lamp Type | 400 Watt Metal Halide | 600 Watt Metal Halide |
| Burning Position | Horizontal | Horizontal |
| Radiation Flux | 110 Watts | 110 Watts |
| Warm-up Time | 2 minutes | 2 minutes |
| Cooling time before Restart | 5 minutes typical | 5 minutes typical |
| Curing Area | 8 x 6’’ minimum | 8 x 6’’ minimum |
| Lamp Life | 1000 hours typical | 1000 hours typical |
| Operating Temperature | +10°C to +40°C
+50°F to +104°F | +10°C to +40°C
+50°F to +104°F |
| Relative Humidity | 30 to 75% operating, 10 to 100% storage | 30 to 75% operating, 10 to 100% storage |
| Cooling | Forced air | Forced air |
| L x W x H (inches) | 11 x 10 x 9 | 11 x 10 x 9 |
