The Dymax ECE 5000 delivers moderate to high UV intensity across a 5" × 5" (12.7 × 12.7 cm) curing area, enabling fast, reliable curing of UV-curable adhesives, coatings, and inks. Designed for versatility, it supports a wide range of industrial applications including bonding, sealing, and encapsulating, and is particularly well-suited for automotive, electronics, optical, and medical device assembly.
The modular design of the ECE Series includes a 400W metal-halide UV bulb, power supply, and reflector housing. Optional accessories—such as shielding, shutters, and mounting stands—allow the system to function as a standalone benchtop unit or be seamlessly integrated into automated production lines.
ECE flood lamp systems are available in fully integrated, ready-to-use packages, offering easy setup, process control, and enhanced safety. They are ideal for curing large bond lines, multi-part trays, or coating and printing applications—making them an excellent choice for prototyping, low-volume production, or R&D environments.
Features
- Powerful UV light-curing lamps (up to 225 mW/cm²)*
- Standard systems contain a metal halide bulb (longwave), but two additional bulb options (shortwave and visible) are available for order
- 100% shielding with safety interlock
- Easy-to-adjust tray height
- Shutter that can be actuated by foot pedal or PLC
- Bulbs are warranted for 2,000 hours**
- Lamp turn-off when the Light Shield door is open
- Containment of non-passive lamp failure
- Reduced light leakage with the new ECE Light Shield design
- Redesigned mounting plate for the ZIP Shutter reduces light leakage
- Measured with Dymax ACCU-CAL 50 Radiometer (325-395 nm) at a lamp height of 3 in (7.62 cm) using a standard metal halide bulb.
- Warranty covers bulb ignition only. Intensity is not warranted.
Specifications:
| Typical Initial Output Intensity at UVA (365 nm) | 225 mW/cm² |
| Curing Area | 5 in x 5 in (12.7 cm x 12.7 cm) |
| Working Distance | 2 in – 6 in (5.08 cm – 15.24 cm) |
| Reflector Housing Dimensions | 6 in L x 6.75 in W x 8 in H (17.2 cm x 17.2 cm x 20.3 cm) |
| Power Supply Dimensions | 12 in L x 16 in W x 4.25 in H (30.5 cm x 40.6 cm x 10.8 cm) |
| Bulb Warranty | 2,000 hours (no intensity warranty, only bulb ignition) |
| Typical Degradation | < 20% over 2,000 hours |
| Power Requirements | 100 – 240 VAC +/-10% Single Phase 47 – 63 Hz |
| Operating Environment | 10-40°C
0-80% non-condensing |
