The L2068 UV LED Flood Lamp is designed for high-performance UV curing over a large 8” × 6” curing area. It features 144 high-power LEDs and delivers peak intensity exceeding 1,900 mW/cm², making it one of the most powerful UV LED flood lamps in its class.
Built to support 365, 395, or 405 nm wavelengths, the L2068 offers programmable curing modes via LCD panel, and can be operated using foot-switch or PLC. It's ideal for stand-alone curing setups, UV chambers, or integration with the Incure C9000™ UV conveyor for high-volume applications.
Features
- Extremely high UV intensity: >1,900 mW/cm² (at 1”)
- Wide 8” × 6” curing area – best in class for flood coverage
- 144 high-performance UV LEDs – even energy distribution
- Wavelength options: 365 / 395 / 405 nm
- Intensity & timing control via LCD
- Smart activation: foot-switch, PLC integration, or standalone
- Active cooling with forced-air design
- LED lifetime > 20,000 hours
- Adjustable curing box & optional interlock safety
Specifications:
| Parameter | Value |
| Model | L2068-365 / L2068-395 / L2068-405 |
| Lamp Type | UV LED Flood |
| Peak Intensity | Distance from Lamp Base 1.0: 1,910 mW/cm2
Distance from Lamp Base 1.5: 1,820 mW/cm2
Distance from Lamp Base 2.0: 1,780 mW/cm2
Distance from Lamp Base 2.5: 1,700 mW/cm2 |
| Curing Area | 8” × 6” (200 × 150 mm) |
| Working Distance | 1.5” – 3” |
| Wavelength Options | 365 / 395 / 405 nm |
| Intensity Adjustment | Yes (0 – 100%) |
| Cooling Method | Forced air with louvers |
| LED Lifetime | >20,000 hours |
| Optional UV Curing Box | B300 / B500 with adapter plate |
| Adjustable Height | 3.5” |
| Power Input | 100–240VAC, 50/60Hz (Auto-ranging) |
| External Control | LCD + PLC + foot-switch |
| Light Head Dimensions | 9.1” × 9.1” × 6.3” |
| Power Supply Dimensions | 13” × 5.1” × 9” |
