| Configuration | Incure C9000 with
L3018 | Incure C9000 with
L1044 | Incure C9000 with
F100x1AB | Incure C9000 with
F200x1AB | Incure C9000 with
F400x1AC | Incure C9000 with
F500x1AC |
| Type of Lamp | LED Beam | LED Flood | ARC Flood | ARC Flood | ARC Flood | ARC Focused |
Intensity @2.5" Distance
UVA(UVV) mW/cm2 | 2,500 (3,000) | 1,800 (87) | 154 (141) | 223(215) | 312 (287) | 436 (390) |
| Intensity Adjustment | YES | YES | NO | YES | NO | NO |
Curing Energy (belt speed)
@ 1.5 feet/min (min)
@ 6.0 feet/min (nominal)
@ 12.0 feet/min (max) | UVA (UVV) mJ/cm2
8,400 (10,000)
2,100 (2,500)
1,050 (1,250) | UVA (UVV) mJ/cm2
24,000 (1,100)
6,000 (300)
3,000 (145) | UVA (UVV) mJ/cm2
4,200 (4,000)
1,050 (1,000)
525 (500) | UVA (UVV) mJ/cm2
8,900 (8,600)
2,200 (2,100)
1,100 (1,050) | UVA (UVV) mJ/cm2
10,400 (9,500)
2,600 (2,300)
1,300 (1,190) | UVA (UVV) mJ/cm2
5,900 (5,500)
1,490 (1,400)
740 (690) |
| Optional Wavelengths | 365, 395, 405 | 365, 395, 405 | 320, 365 | 320, 365 | 254, 365 | 254, 365 |
| Recommended Working Distance | 1.5" -3" | 0.2" - 3" | 1.5" -3" | 1.5" -3" | 1.5" -3" | 1.5" -3" |
| Expected Bulb Life | >20,000 hrs | >20,000 hrs | >1,000 hrs | >1,000 hrs | >1,000 hrs | >1,000 hrs |
| Intensity Decay over Life | 20% | 20% | 45% | 45% | 45% | 45% |
Maximum Part Cure Width
Exposure Width | 8"
1" | 4"
4" | 8"
6" | 8"
6" | 5"
5" | 5"
3" |
| Stand-Alone Configuration | YES | YES | YES | YES | YES | YES |
| Dynamic Uniformity | 0.9 @ 3.0" distance | 0.9 @ 3.0" distance | 0.78 @ 3.0" distance | 0.78 @ 3.0" distance | 0.79 @ 3.0" distance | 0.79 @ 3.0" distance |
| Temperature Management | Air-cool | Air-cool | Air-cool or External Exhaust | Air-cool or External Exhaust | Air-cool or External Exhaust | Air-cool or External Exhaust |
| Power Input | 100-240V, 50/60Hz
Auto-Ranging | 100-240V, 50/60Hz
Auto-Ranging | 100-240V, 50/60Hz
Auto-Ranging | 100-240V, 50/60Hz
Auto-Ranging | 100-240V, 50/60Hz
Auto-Ranging | 100-240V, 50/60Hz
Auto-Ranging |
| External Control Port | PLC/RS232/Foot Switch | PLC/RS232/Foot Switch | None | None | None | None |
Light Source Dimension
Power Supply Dimension
Conveyor Dimension | 10.3" x 3.6" x 4" (2.5Kg)
13" x 9" x 5.1" (6.6Kg)
54" x 14" x 12" | 5.1" x 5.1" x 6.3"
13" x 9" x 5.1"
54" x 14" x 12" | 11" x 10" x 9"
Intergrated With Light Source
54" x 14" x 12" | 11" x 10" x 9"
Intergrated With Light Source
54" x 14" x 12" | 8" x 5" x 6"
Intergrated With Light Source
54" x 14" x 12" | 8" x 5" x 6"
Intergrated With Light Source
54" x 14" x 12" |
| Conveyor Curing Height | 1.5" - 5" | 1.5" - 5" | 1.5" - 5" | 1.5" - 5" | 1.5" - 5" | 1.5" - 5" |
| Belt Width | 9" | 9" | 9" | 9" | 9" | 9" |
| Ordering Part Number | Ordering Part Number C9000-1xL3018-365
C9000-1xL3018-385
C9000-1xL3018-405 | C9000-1xL1044-365
C9000-1xL1044-385
C9000-1xL1044-405 | C9000-F100x1AB
C9000-F100x2A
C9000-F100x2B | C9000-F200x1AB
C9000-F200x2A
C9000-F200x2B | C9000-F400x1AC
C9000-F400x2A
C9000-F400x2C | C9000-F500x1AC
C9000-F500x2A
C9000-F500x2C |
